Preparing a Traction Engine for Show Season

The Season Begins in the Workshop

Show season has a way of arriving far faster than anyone expects. The first rally may be months off, but a traction engine has a long memory, and anything neglected in February will announce itself in July — usually in front of an audience. Treat the winter as your preparation window. Draw up a list, work through it methodically, and leave yourself a fortnight of slack before your first outing. Nothing takes the shine off a rally like a last-minute thrash on the pit.

Begin with a slow walk round the engine as though you had never seen it before. Look for the obvious: blistered paint, loose fittings, a weeping gland, brake blocks worn thin, a steering chain with more slack than it should have. Make notes rather than reaching straight for a spanner, then sort the jobs into those that need the boiler empty and those that can wait until spring.

Cleaning and Polishing Is Not Vanity

A clean engine is easier to inspect, and dirt hides trouble. Start with paraffin and a soft brush on the oily areas — around the motion, the lubricator, the hornplates and the front axle — then wipe down with clean cotton waste. Grease that has dried to a varnish will come away with patience and a little warmth, not with a scraper.

Brasswork rewards care. Work the polish in with a soft cloth, let it haze, then buff it off before it dries hard, and finish the fiddly corners with a brush. On the copper and brass fittings, a thin film of oil afterwards will slow the tarnish. Paintwork wants a wash, a check for stone chips, and a touch-up with a matching brush where the rust is starting to bloom. Smokebox and chimney traditionally take a graphite dressing rather than gloss, which also makes next year's cleaning simpler.

Brakes, Steering and the Motion

Brakes are the first mechanical port of call, and for good reason. Check the blocks for wear and glazing, work the adjusters through their full travel, and look hard at every pin, clevis and cotter in the linkage. If the brake band or drum shows scoring, deal with it now. Test on a quiet private surface before you trust it on a rally field slope.

Steering wants the same attention. Examine the chains for stretched links, the sprockets for hooked teeth, and the front axle pins and bushes for play. A little lost motion at the wheel is acceptable; a lot is not.

Then move to the motion. Check the slide bars and crosshead for wear, the big and little end bearings for shims and tightness, and every split pin and nut. Top up grease cups, clear out the lubricator, and inspect the eccentric strap and valve gear for anything that has worked loose over the winter. New gland packing now saves a wet, steamy afternoon later.

Boiler, Firebox and Paperwork

The boiler deserves unhurried attention. With the firebox cold and clean, look at the tube plate, the stays and the crown stays, the firebars and grate, and the ashpan and damper operation. Confirm the fusible plug is sound, the gauge glass and cocks are clear and correct, and the safety valves are set and sealed as they should be. Exercise the injector and the feed pump, check the clack valves and the blowdown, and make sure the pressure gauge reads sensibly.

Your certificate is not a formality. Check the expiry date against your first rally entry, and book any inspection or hydraulic and steam test well ahead — inspectors get busy in spring. Keep the certificate, the written scheme of examination and the insurance documents together in one folder, and take copies to every event. Bring spare gauge glasses, jointing, fusible plugs and a set of hand tools in a proper rally crate.

Insurance, Transport and Entries

Arrange insurance early. You will want public liability cover at a sensible limit, road risk if the engine ever travels under its own steam on the highway, and confirmation that your policy covers rally display and movement on site. Read the small print on age and experience conditions.

Transport books up fast. Approach your haulier as soon as the rally dates are known, agree loading times, and confirm the engine's dimensions and weight. On the day, chock the wheels, secure with proper chains over the axles rather than the spokes, and check the chimney and canopy clear the low-loader's height limit. Get the entry forms in before the closing dates, and read the rally pack for water, coal and movement rules.

The First Fire-Up

Treat the first light-up as a dress rehearsal. Raise steam gently, keep the fire modest, and let everything warm through before working it hard. Run the injector and pump, watch the gauge glass, check for weeps at every joint, and re-tighten glands once the engine is hot. Do a few steady laps on private ground, test the brakes and steering properly, and adjust the lubricator feed until the motion is running sweet. Only then load up and head for the first rally — with clean brasses, sound paperwork, and the quiet confidence of a job done properly.
